| Product Description |
Details |
| Wattage |
35 Watt
|
| Features & Benefits |
• Delivers excellent illumination & comfort
• Long life & photobiologically safe LEDs
• High performance electronic driver ensures zero maintenance
• No harmful UV & IR radiations
• Environment friendly as it does not contain Mercury
• Instant light with low running temperatures
• Operating temperature:- upto 45 °C
• Operating voltage range: 140 V - 270 V
• Average life L70B50: 50000 hours |
| Housing
|
Die-cast aluminum spigot for mounting LED driver and spun aluminum canopy which is painted white inside. |
| Finish |
Pure polyester UV protected powder coated matt black finish after phosphochromate treatment. |
| Light Source |
High efficiency long life LED module with SMD LED package mounted on MCPCB. Lumen efficacy of LED >140 lm/W and viewing angle of 120° to ensure better uniformity (For detailed photometric data,please refer LM79 report & IES file). |
| Cover |
High quality polycarbonate cover is used over LED module to enhance the lumen output & clear acrylic diffuser is used to provide overall glare free light. |
| Electronic Driver |
Powered by Built In potted , isolated electronic LED driver with APFC (SMPS based constant current supply) with lower THD, Output Short /Open Circuit protection, Over Voltage protection,
Surge Voltage protection upto 10kv with SPD & other safety test as per IS 15885 Part-2/Sec 13. |
| Mounting |
Suitable for pole mounting with OD of 76 mm max with 4 nos. hex bolt M6 X 20 mm provided with the fixture. |
| Applications |
City avenues
Shopping malls
Heritage buildings
Public gardens/parks |
| IP Rating |
IP65 |
| IK Rating |
IK07 |
| Nominal Voltage (V) |
240 V |
| Mains Current (A) |
0.17 |
| Power Factor |
>0.95 |
| THD (%) |
<10 |
| Colour Temp. (CCT) |
5700K |
| CRI (Ra) |
>70 |
| System Lumens (lm) |
3500lm |
| Colour of Fixture |
Black |
| Weight (kg) |
2.500 kg |
| Height (H) |
405 mm |
| Mounting Hole Distance (d) |
76 mm |
| Warranty
|
2 Years |
