HAVELLS LUMILINE PLUS PRO 10 WATT LED BATTEN 6500 K
Code:
Surface and wall mounted LED batten with 100lm/W system efficacy, extruded aluminum housing provided for efficient heat dissipation with polycarbonate diffuser & integrated electronic driver with <10% THD. Item Code:- LUMILINEPLUSPROBS10WLED865SPCSSIND Product Details:- Product Description Details Wattage 10 Watt Features & Benefits • Excellent...
Request a personalised quote
Need a bulk order or project quotation? Send your requirements for a personalised quote.
No obligation. Just your quote.
Product Details
Surface and wall mounted LED batten with 100lm/W system efficacy, extruded aluminum housing provided for efficient heat dissipation with polycarbonate diffuser & integrated electronic driver with <10% THD. Item Code:- LUMILINEPLUSPROBS10WLED865SPCSSIND
Product Details:-
| Product Description | Details |
| Wattage | 10 Watt |
| Features & Benefits | • Excellent efficacy & performance . • Long life & photobiologically safe LEDs • High performance electronic driver ensures zero maintenance • No harmful UV & IR radiations • Environment friendly as it does not contain Mercury • Instant light with low running temperatures • Operating temperature: -10 °C to +35 °C • Operating voltage range: 140 V - 270 V • Average life L70B50: 50000 hours |
| Housing | Made of Aluminum Extrusion with housing part in Anodize finish & diffuser part in opal finish. |
| Electronic driver | Powered by an integral electronic driver (SMPS based constant current supply) with Output Short circuit protection, Surge protection & other safety test as per IS:15885 Part 2/Sec 13. |
| Mounting | Can be fixed directly into the wall/ ceiling by means of mounting clips provided with the fixture. |
| End caps | ABS end caps are snap fitted to the fixture. |
| Lamp | High efficiency long life LED with lumen efficacy of 140 lm/W with viewing angle of 120º (For detailed photometric data, please refer LM79 report & IES files). |
| Applications | Residences Showrooms Cove lighting Hospital premises Educational institutions Corridors |
| Operating Usage | Max 12hrs/Day |
| IP Rating | IP20 |
| Nominal Voltage (V) | 240V |
| Mains Current(A) | 0.045 |
| Power Factor | >0.95 |
| THD (%) | ≤10 |
| CCT | 6500K |
| CRI | ≥80 |
| System Lumen(lm) | 1100 Lumens |
| Colour of Fixture | Silver |
| Weight (kg) | 0.150 kg |
| Length (l) | 550 mm |
| Width (w) | 23 mm |
| Height (h) | 33 mm |
