Recess mounted downlighter with pressure die-cast aluminium heat sink & PC diffuser in white powder coated finish with integral electronic low THD (<10%) LED driver. Item Code:-INTEGRANEODLR24WLED840S Product Details:- Product Description Details Wattage 24 Watt Features & Benefits Delivers excellent illumination & comfort in high ceiling areas• Long life & photobiologically...
Recess mounted downlighter with pressure die-cast aluminium heat sink & PC diffuser in white powder coated finish with integral electronic low THD (<10%) LED driver. Item Code:-INTEGRANEODLR24WLED840S
Product Details:-
| Product Description | Details |
| Wattage | 24 Watt |
| Features & Benefits | Delivers excellent illumination & comfort in high ceiling areas • Long life & photobiologically safe LEDs • High performance electronic driver ensures zero maintenance • No harmful UV & IR radiations • Environment friendly as it does not contain Mercury • Instant light with low running temperatures • Operating temperature: -10 °C to +45 °C • Operating voltage range: 140 V - 270 V • Average life L70B50: 50000 hours |
| Housing & Finish | White powder coated, elegantly designed pressure die-cast aluminium heat sink for efficient dissipation & white finish polycarbonate ring for holding the diffuser. |
| Light Source | High efficiency long life SMD LED mounted on MCPCB with high LED efficacy of 140 lm/W used to enhance the lumen output. |
| Reflector | High reflective polycarbonate conical shaped reflector to enhance the lumen output of the fixture. |
| Optics | High quality polycarbonate opal concave diffuser to enhance the aesthic of the fixture and to provide glare free uniform light distribution (For detailed photometric data,please refer LM79 report & IES file). |
| Electronic Driver | Powered by integral SMPS based constant current electronic driver with lower THD, Output Short Circuit Protection, Surge Voltage Protection and other safety tests as per IS 15885 Part 2/ Sec 13. |
| Mounting | Fixing into false ceiling by 2 nos. SS springs/clips. |
| Applications | Residences Restaurants Hotel lobbies / Waiting areas Modern gyms / Spa Corporate offices |
| IP Rating | IP20 |
| Nominal Voltage (V) | 240 V |
| Mains Current (A) | 0.110 A |
| Power Factor | 0.95 |
| THD (%) | ≤10 |
| Colour Temp. (CCT) | 4000 K |
| CRI (Ra) | ≥80 |
| System Lumens (lm) | 2280 lm |
| Colour of Fixture | White |
| Weight (kg) | 0.840 kg |
| Height (H) | 90 mm |
| Cutout Size (in mm) | Ø175 mm |
